Features

• Rugged construction stands up industrial use
• Chequered plate surface for added grip
• Bright LED display for easy viewing in most environments
• Adjustable levelling feet help optimize setup
• Lightweight design simplifies transport and portability
• Rugged construction stands up to industrial use
• External calibration allows for verification and adjustments with weights
• Sealed keypad protects against dirt and spills
• Wall-mount bracket for placing indicator on vertical surface
• Colour-coded keys facilitate quick recognition
• Rechargeable battery included for operation almost anywhere
• Heavy duty rubber feet ensure stability of unit
• Overload protection helps prevent damage to internal components
• Large, grade 202 stainless steel platter, console stand and back grill
• Programmable auto power-off to save energy

General Specifications

• Weighing units: kg, g
• Calibration: External calibration
• Display housing: ABS Plastic
• Operating temperature: 0˚C to 45˚C
• Display: Green LED with 25.4 mm-Height Digit

Optional Reports

• Printer
• RS-232 Interface
• RS-485 Modbus RTU
• 4-20mA output
• Kg to letter conversion
• Check weighing
• Remote display (Pole/Wall Mounting)
• Tower lamps (Red, Yellow & Green)
• Two relay out-put for PLC.
• USB interface
• Remote display

Printing Details

• Header 3 Line each line 24 Character
• Paper width: 2.2 inch maximum (56mm)
• Memory: 999 No. (Only Gross Weight)
• Real time clock with backup support
• Serial No. Auto Increment
• Date & Time Auto
• Gross Weight: Auto
• Tare Weight: Auto
• Net Weight: Auto

Techanical Specification

Capacity (kg.)	Accuracy (g)	Platform Size (mm)	Framework	Platter
50/100/200	5/10	400X400	MS	SS/MS
100/200/300	10/20/50	500X500	MS	SS/MS
100/200/300/500	10/20/50/50	600X600	MS	SS/MS
300/500/1000	50/50	750X750	MS	MS/SS
500/1000/2000	50/100	900X900	MS	MS/SS
500/1000/2000	50/100/200	1000X1000	MS	MS/SS
1000/2000/3000	100/200/500	1200X1200	MS	MS/SS
1000/2000/3000/5000	100/200/500/500	1500X1500	MS	MS/SS
