Features

• For easy movement of material
• Smooth dust resistant roller and ramps
• Roller MOC: MS or SS
• Auto zero tracking
• High Accurate Load Cell Based Scale
• S.S./M.S. sturdy grill
• Rugged Square Pipe 25x50mm Structure
• ABS Body Indicator on adjustable separate/Attached pole
• S.S./M.S. Checkered Platform
• Auto calibration
• Auto power saving function
• User friendly operation
• 6 Digit Red Led Display (14mm Height)
• Kg. /Letter. Conversion Facility
• Piece Counting
• Inbuilt battery backup
• 6V 4AH Rechargeable Battery
• Dual/triple accuracy.
• Corner Overload Protection

General Specifications

• Weighing units: kg, g
• Calibration: External calibration
• Display housing: ABS Plastic
• Operating temperature: 0˚C to 45˚C
• Display: Green LED with 25.4 mm-Height Digit

Optional Reports

• Printer
• RS-232 Interface
• RS-485 Modbus RTU
• 4-20mA output
• Kg to letter conversion
• Check weighing
• Remote display (Pole/Wall Mounting)
• Tower lamps (Red, Yellow & Green)
• Two relay out-put for PLC.
• USB interface
• Remote display

Technical Specification
